P2.5 LED Video Wall offers a cost-effective display solution for the mid to high-end market, featuring an ultra-slim cabinet design and exceptional value for money. This product merges a fine pixel pitch with a compact industrial design, meeting a wide array of needs from conference rooms to large event venues.
High Cost Performance: Maintains high quality while offering a competitive price, suitable for customers with budget constraints but demanding display effects.
Ultra-Slim Cabinet Design: The slim profile is not only aesthetically pleasing but also facilitates easy installation and transportation, saving space.
High Refresh Rate: Ensures smooth motion without flickering, ideal for sports events and fast-moving video playback.
Low Power Consumption: Optimized power design for energy-efficient operation, reducing long-term operational costs.
Wide Viewing Angle: Wide viewing angle technology ensures a clear image from various perspectives.
Front Maintenance Convenience: Supports front maintenance for quick repairs and module replacement, minimizing maintenance costs.
| No. | Items | Indoor P2 | Indoor P2.5 | Indoor P3 | Indoor P4 | Indoor P5 |
| 1 | Pixel Pitch | 2.0mm | 2.5mm | 3.076mm | 4.0mm | 5.0mm |
| 2 | LED Configuration | SMD1515 | SMD2020 | SMD2020 | SMD2020 | SMD2020 |
| 3 | Module Size | 320*160mm | ||||
| 4 | Module Resolution | 160*80dots | 128*64dots | 104*52dots | 80*40dots | 64*32dots |
| 5 | Cabinet Size (WXHXD) | 640*480*58mm | ||||
| 6 | Cabinet Resolution(WXH) | 320*240dots | 256*192dots | 208*156dots | 160*120dots | 128*96dots |
| 7 | Pixel Density | 250,000 dots/㎡ | 160,000 dots/㎡ | 105,688 dots/㎡ | 62,500 dots/㎡ | 40,000 dots/㎡ |
| 8 | Materail | Die-casting Aluminum | ||||
| 9 | Cabinet Weight | 6KG | ||||
| 10 | Brightness | ≥800cd/㎡ | ||||
| 11 | View Angle | H 140°，W 140° | ||||
| 12 | Best View Distance | ≥2m | ≥2m | ≥3m | ≥4m | ≥5m |
| 13 | Gray Scale | 14~16bit | ||||
| 14 | Refresh Rate | ＞3840HZ | ||||
| 15 | Frame changing frequency | 60fps | ||||
| 16 | Input voltage | AC 86-264V/60Hz | ||||
| 17 | Power Consumption (Max/Avg) | 600/300W/㎡ | ||||
| 18 | Screen weight | 20kg/㎡ | ||||
| 19 | MTBF | >10,000 hrs | ||||
| 20 | Service life | ≥100,000 hrs | ||||
| 21 | IP Rate | IP43 | ||||
| 22 | Temperature | Working:﹣10℃～+65℃ or Storage:﹣40℃～+85℃ | ||||
| 23 | Humidity | 10%-90%RH | ||||
Conference Rooms and Lecture Halls: Enhances the professionalism of meetings and presentations as a high-definition display screen.
Control Rooms and Surveillance Centers: Provides clear video monitoring images to improve surveillance efficiency.
Commercial Advertising: Attracts customer attention as an advertising screen in commercial environments such as shopping malls and hotels.
Stage Rentals: Serves as a stage backdrop or effect screen to enhance the visual impact of performances.
Public Information Displays: Displays directional information and announcements in public spaces like airports and train stations.
Q: What is the cost performance of the P2.5 LED Video Wall?
A: The P2.5 LED Video Wall offers a high cost-performance ratio, ensuring quality while providing a competitive price.
Q: What does the ultra-slim cabinet design entail?
A: The ultra-slim cabinet design refers to the reduced thickness of the LED display cabinet, which enhances aesthetics and simplifies installation and transportation.
Q: Is the video wall suitable for dynamic video content?
A: Yes, with a high refresh rate, the P2.5 LED Video Wall is well-suited for dynamic video content, including sports events and fast-paced videos.
Q: What is the power consumption of the video wall?
A: The P2.5 LED Video Wall is designed for low power consumption, making it cost-effective for long-term operation and suitable for projects with budget constraints.
Q: Is maintenance and module replacement convenient?
A: The P2.5 LED Video Wall offers front maintenance, making it quick and easy to service and replace modules.
Hexshine's P2.5 LED Video Wall, with its high cost-performance and ultra-slim cabinet design, provides an ideal choice for clients seeking an economical yet practical display solution. We are committed to delivering quality products and services to meet a variety of professional display needs.
