An indoor P1.6 fixed installation LED video wall with 640x480mm panels offers a high-resolution and visually captivating display solution for various indoor applications.
P1.6 Pixel Pitch
Provides sharp and vivid visuals, suitable for close viewing distances (around 1 meters and above). Text and high-resolution images will appear clear and detailed.
640x480mm Panels
This is a common panel size for indoor LED video walls, offering a good balance between modularity and resolution.
Fixed Installation
Designed for permanent mounting in a specific location.
High Resolution
Ideal for displaying detailed content like presentations, videos, or high-quality images.
Seamless Viewing Experience
Individual panels are closely spaced, creating a unified picture without noticeable bezels (gaps) between panels (depending on the specific model).
| No. | Items | Indoor P1.2 | Indoor P1.5 | Indoor P1.6 | Indoor P1.8 |
| 1 | Pixel Pitch | 1.25mm | 1.538mm | 1.667mm | 1.86mm |
| 2 | LED Configuration | SMD1010 | SMD1212 | SMD1212 | SMD1515 |
| 3 | Module Size | 320*160mm | |||
| 4 | Module Resolution | 256*128dots | 208*104dots | 192*96dots | 172*86dots |
| 5 | Cabinet Size (WXHXD) | 640*480*58mm | |||
| 6 | Cabinet Resolution(WXH) | 320*240dots | 256*192dots | 208*156dots | 160*120dots |
| 7 | Pixel Density | 640,000 dots/㎡ | 422,754 dots/㎡ | 359,856 dots/㎡ | 289,050 dots/㎡ |
| 8 | Materail | Die-casting Aluminum | |||
| 9 | Cabinet Weight | 6KG | |||
| 10 | Brightness | ≥800cd/㎡ | |||
| 11 | View Angle | H 160°，W 160° | |||
| 12 | Best View Distance | ≥1m | ≥1.5m | ≥1.5m | ≥1.8m |
| 13 | Gray Scale | 16~18bit | |||
| 14 | Refresh Rate | ＞3840HZ | |||
| 15 | Frame changing frequency | 60fps | |||
| 16 | Input voltage | AC 86-264V/60Hz | |||
| 17 | Power Consumption (Max/Avg) | 600/300W/㎡ | |||
| 18 | Screen weight | 20kg/㎡ | |||
| 19 | MTBF | >10,000 hrs | |||
| 20 | Service life | ≥100,000 hrs | |||
| 21 | IP Rate | IP43 | |||
| 22 | Temperature | Working:﹣10℃～+65℃ or Storage:﹣40℃～+85℃ | |||
| 23 | Humidity | 10%-90%RH | |||
Retail stores
Showcase products with high-resolution visuals and dynamic displays to attract customers.
Corporate lobbies and reception areas
Create a lasting impression with a visually striking display.
Control rooms and situational awareness centers
Deliver sharp and clear information for critical decision-making.
Conference rooms and meeting spaces
Enhance presentations and share high-resolution content.
Broadcast studios and control rooms
Display live feeds and program content with excellent clarity.
Museums and exhibitions
Showcase exhibits in an engaging and informative way.
